The 883 water filling machine is a professional water filling machine suitable for bottled water and other packaging needs, efficiently completing quantitative water filling operations. It offers stable operation, balances precision and efficiency, and can accommodate bottles of various sizes. It supports necessary quality inspections to ensure hygienic filling conditions. Its comprehensive after-sales service system helps beverage companies achieve standardized water filling production and meet batch processing needs.
The 883 Water Filling Machine is a game - changer for small to medium - sized water bottling businesses. With a production capacity of 2000 - 3000 bottles per hour (e.g., 500 - ml bottles), it strikes a perfect balance between efficiency and cost - effectiveness.
This machine features an 8 - 8 - 3 monoblock design, integrating 8 rinsing heads, 8 filling heads, and 3 capping heads into one compact unit. This not only saves significant space in your facility but also ensures synchronized operation. The fully automatic operation, controlled by a PLC system, reduces manual labor and allows for easy and precise control over the entire bottling process. It can handle plastic PET bottles with diameters ranging from 50 - 115 mm and heights from 160 - 320 mm. Plus, it's highly customizable, capable of producing different volumes and shapes of bottled water by changing the shape mold to meet various user demands.
Voltage | 380V |
---|---|
Weight (KG) | 1800 |
packaging material | plastic, Metal, Glass |
filling accuracy | ±1% |
dimension(l*w*h) | 1800x1500x2000mm / 2300x1700x2000mm |
filling nozzle | 8 |
Filling range | 25-250ml/50-500ML./100-1000ML/250-2500ML |
Bottle diameter | 50-100mm |
Bottle height | 150-350mm |
Bottle washing water consumption | 3-8m³/h |
Capping torque range | 5 - 20Nm |
Applicable bottle cap | Diameter 25 - 40mm |
Air source pressure | 0.6 - 0.8MPa |
Hope our machine is what you need
Our clients come from over 80 countries.
The factory is located in Zhengzhou, Henan Province.
One year after-sales service guarantee.
High standard, high-quality machines.
